A-Frame Vegetable Trellis

Model BT003D

Three A-shaped supports are joined by one ridge rail and two side rails. Custom connectors hold the cross points, and A-clamps close around the ridge tube. Trellis netting or plant ties can be fixed to either side, with both outer faces open for tying stems and picking crops.

12 mm plastic-coated twisted-pattern steel tube
Custom cross connectors and Type A clamps
120 × 120 and 160 × 160 cm length-and-height options
Side rails for attaching netting or plant ties

Suitable for

Pole and runner beans Peas and sweet peas Cucumbers in raised beds

Request a Quote View Garden Trellises

Specifications

Match the frame to the raised-bed row: 120 cm for a shorter section, or 160 cm for a longer run. Assemble the three A-shaped supports first, then connect the ridge and side rails before adding netting or plant ties.

Length × Height (cm)	Packing Size (cm)	G.W. (kg)	N.W. (kg)
120 × 120	44 × 23 × 7.5	4.5	4.0
160 × 160	44 × 23 × 8.5	5.8	5.1
